EOD/Bomb Jammer

EOD/Bomb Jammer are professionally designed to protect VIPs, Military/Security staff or EOD teams from RCIEDs used by terrorist.

OVERVIEW

EOD/Bomb Jammer is designed based upon our RF technology. Applying advance electronic engineering, it transmit accurate RF jamming signal to interfere mobile receiver. Our jammer series designed for many purposes such as manpack, transportable and buit-in vehicle to suit with specific requirements

Manpack

TRANSPORTABLE ​

Vehicle

Manpack

TRANSPORTABLE

Vehicle

Manpack

Jammer Manpack DRC

FEATURES

  • Frequency jamming bands: RC, VHF, UHF, Cellular, WiFi
  • Selectable Operating Modes: Remote control, Radio, Cellular or all
  • Jamming distance: 30 meters
  • High gain Omni-Directional antennas
  • Battery level Indicator and Status alert
  • Remote Control Operation
  • MIL-STD 810G
  • IP65

SPECIFICATION

Jamming Module

Frequency
27 MHz
35/ 40/ 49 MHz
315/ 434 MHz
136 - 174 MHz
400 - 500 MHz
869 - 960 MHz
1805 - 1880 MHz
2110 - 2170 MHz
2400 - 2690 MHz
Power
≥ 1 Watt
≥ 1 Watt
≥ 1 Watt
≥ 5 Watt
≥ 5 Watt
≥ 2.5 Watt
≥ 2.5 Watt
≥ 2.5 Watt
≥ 2.5 Watt

Jamming Distance

≥ 30 meters

Power Supply

Battery | Li-ion 24 VDC
Backup time | More than 2 hours
Battery charger included | 220VAC, 50Hz,Automatic charging controlled by microcontroller and stop when battery is fully charged

Protection system

High VSWR / antenna mis-match protection
Over current protection
Surge Protection

Environment

Operating temperature | -10°C to 60°C
Heat dissipation | Heat Sink (Fanless Design)

Standard

MIL-STD 810G
IP65

Transportable

FEATURES

  • Frequency jamming 6 bands ( cover GSM, 3G, 4G, 5G)
  • Selectable band jamming
  • Jamming distance: 30 meters
  • High gain Omni-Directional antennas
  • Battery level Indicator and Status alert
  • Remote Control Operation
  • MIL-STD 810G
  • IP65
jammer DRC

SPECIFICATION

Jamming Module

Frequency
758 - 803 MHz
869 - 960 MHz
1805 - 1880 MHz
2110 - 2170 MHz
2400 - 2690 MHz

Total output power

>= 50 Watts

Jamming Distance

≥ 30 meters

Power Supply

Battery | Li-ion 24 VDC
Backup time | More than 2 hours
Battery charger included | 220VAC, 50Hz,24 VDC Automatic charging controlled by microcontroller and stop when battery is fully charged

Protection system

High VSWR / antenna mis-match protection
Overload Protection
Surge Protection

Environment

Operating temperature | -10°C to 60°C
Heat dissipation | Heat Sink (Fanless Design)

Standard

MIL-STD 810G
IP55

Vehicle

Convoy Jammer EOD/Bomb Jammer DRC
Convoy Jammer EOD/Bomb Jammer DRC

FEATURES

  • Jamming up to 10 frequency bands: RC, VHF, UHF, Cellular, WiFi
  • Selectable band jamming
  • Remote Control Operation
  • 3 hours operating continuous when using battery
  • Power supply with AC 220 Volts and direct from battery
  • External Omni-Directional antenna with electric motor to fold antenna
  • Installed in 19” Rack with MIL-STD 810G and MIL-DTL-5015
  • Customization is available based on customer requirement
EOD/Bomb Jammer DRC

Remote Control

  • System remote control with tablet
  • 10” Rugged Tablet (Touch Screen Display)
  • GUI (Graphic User Interface)
  • On/Off switch for each frequency band
  • Sound and light Alert

SPECIFICATION

Jamming Frequency

Remote control 27, 35, 40, 49, 315, 434 MHz
Radio: 136-174 MHz, 245-247 MHz, 400-460 MHz, 460-520 MHz :
Cellular 4G/5G: 758 – 803 MHz, 869 – 960 MHz, 1805 – 1880 MHz, 2110 – 2170 MHz, 2310 – 2370 MHz, 2500 – 2690 MHz, 2600 - 2690 MHz,
Wi-Fi: 2400 – 2500 MHz, 5720 – 5850 MHz

Total output power

>= 1200 Watts

Jamming Distance

≥ 100 meters

Power Supply

Power supply and charger | 220 VAC / 50 Hz, 24 VDC
Battery | Lithium Phosphate

Protection system

High VSWR / antenna mis-match protection
Overload Protection
Surge Protection

Environment

Heat dissipation | Heat Sink (Fanless Design)
Operating temperature | -10°C to 60°C
Product Gallery
Previous
Next

AppliCATIONs

Military Base Protection

VIP Protection

Border Protection

Critical Infrastructure Protection
